78 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
n/a :ACQuire:POINts? (see
page 200)
<# points> ::= an integer in NR1
format
:ACQuire:RSIGnal
<ref_signal_mode>
(see page 201)
:ACQuire:RSIGnal?
(see page 201)
<ref_signal_mode> ::= {OFF | OUT
| IN}
:ACQuire:SEGMented:AN
ALyze (see page 202)
n/a n/a (with Option SGM)
:ACQuire:SEGMented:CO
UNt <count> (see
page 203)
:ACQuire:SEGMented:CO
UNt? (see page 203)
<count> ::= an integer from 2 to
2000 (w/8M memory) in NR1 format
(with Option SGM)
:ACQuire:SEGMented:IN
Dex <index> (see
page 204)
:ACQuire:SEGMented:IN
Dex? (see page 204)
<index> ::= an integer from 2 to
2000 (w/8M memory) in NR1 format
(with Option SGM)
n/a :ACQuire:SRATe? (see
page 207)
<sample_rate> ::= sample rate
(samples/s) in NR3 format
:ACQuire:TYPE <type>
(see page 208)
:ACQuire:TYPE? (see
page 208)
<type> ::= {NORMal | AVERage |
HRESolution | PEAK}
Table 4 :ACQuire Commands Summary (continued)
Command Query Options and Query Returns
Table 5 :BUS<n> Commands Summary
Command Query Options and Query Returns
:BUS<n>:BIT<m> {{0 |
OFF} | {1 | ON}} (see
page 212)
:BUS<n>:BIT<m>? (see
page 212)
{0 | 1}
<n> ::= 1 or 2; an integer in NR1
format
<m> ::= 0-15; an integer in NR1
format
:BUS<n>:BITS
<channel_list>, {{0 |
OFF} | {1 | ON}} (see
page 213)
:BUS<n>:BITS? (see
page 213)
<channel_list>, {0 | 1}
<channel_list> ::= (@<m>,<m>:<m>
...) where "," is separator and
":" is range
<n> ::= 1 or 2; an integer in NR1
format
<m> ::= 0-15; an integer in NR1
format
:BUS<n>:CLEar (see
page 215)
n/a <n> ::= 1 or 2; an integer in NR1
format
:BUS<n>:DISPlay {{0 |
OFF} | {1 | ON}} (see
page 216)
:BUS<n>:DISPlay? (see
page 216)
{0 | 1}
<n> ::= 1 or 2; an integer in NR1
format
