Obsolete and Discontinued Commands 7

Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 729

:MEASure:TMAX

(see page 798)

Command Syntax

:MEASure:TMAX [<source>]

<source> ::= {CHANnel<n> | FUNCtion | MATH}

<n>::={1|2|3|4}forthefour channel oscilloscope models

<n> ::= {1 | 2} for the two channel oscilloscope models

The :MEASure:TMAX command installs a screen measurement and starts

an X- at- Max-Y measurement on the selected waveform. If the optional

source is specified, the current source is modified.

Query Syntax

:MEASure:TMAX? [<source>]

The :MEASure:TMAX? query returns the horizontal axis value at which the

maximum vertical value occurs on the current source. If the optional

source is specified, the current source is modified. If all channels are off,

the query returns 9.9E+37.

Return Format

<value> ::= time at maximum in NR3 format

See Also • "Introduction to :MEASure Commands" on page 324

• ":MEASure:TMIN" on page 730

• ":MEASure:XMAX" on page 368

• ":MEASure:XMIN" on page 369

NOTE

The :MEASure:TMAX command is obsolete and is provided for backward compatibility to

previous oscilloscopes. Use the :MEASure:XMAX command (see page 368) instead.
