:TRIGger:UART:SOURce:
RX <source> (see
page 619)
:TRIGger:UART:SOURce:
RX? (see page 619)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:UART:SOURce:
TX <source> (see
page 620)
:TRIGger:UART:SOURce:
TX? (see page 620)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:UART:TYPE
<value> (see
page 621)
:TRIGger:UART:TYPE?
(see page 621)
<value> ::= {RSTArt | RSTOp |
RDATa | RD1 | RD0 | RDX |
PARityerror | TSTArt | TSTOp |
TDATa | TD1 | TD0 | TDX}
:TRIGger:UART:WIDTh
<width> (see
page 622)
:TRIGger:UART:WIDTh?
(see page 622)
<width> ::= {5 | 6 | 7 | 8 | 9}
Table 92 :TRIGger:UART Commands Summary (continued)
Command Query Options and Query Returns
