Commands by Subsystem 5
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 593
:TRIGger:SPI Commands
Table 89 :TRIGger:SPI Commands Summary
Command Query Options and Query Returns
:TRIGger:SPI:CLOCk:SL
OPe <slope> (see
page 594)
:TRIGger:SPI:CLOCk:SL
OPe? (see page 594)
<slope> ::= {NEGative | POSitive}
:TRIGger:SPI:CLOCk:TI
Meout <time_value>
(see page 595)
:TRIGger:SPI:CLOCk:TI
Meout? (see page 595)
<time_value> ::= time in seconds
in NR1 format
:TRIGger:SPI:FRAMing
<value> (see
page 596)
:TRIGger:SPI:FRAMing?
(see page 596)
<value> ::= {CHIPselect |
NOTChipselect | TIMeout}
:TRIGger:SPI:PATTern:
DATA <value>, <mask>
(see page 597)
:TRIGger:SPI:PATTern:
DATA? (see page 597)
<value> ::= integer or <string>
<mask> ::= integer or <string>
<string> ::= "0xnnnnnn" where n
::= {0,..,9 | A,..,F}
:TRIGger:SPI:PATTern:
WIDTh <width> (see
page 598)
:TRIGger:SPI:PATTern:
WIDTh? (see page 598)
<width> ::= integer from 4 to 32
in NR1 format
:TRIGger:SPI:SOURce:C
LOCk <source> (see
page 599)
:TRIGger:SPI:SOURce:C
LOCk? (see page 599)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:SPI:SOURce:D
ATA <source> (see
page 600)
:TRIGger:SPI:SOURce:D
ATA? (see page 600)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:SPI:SOURce:F
RAMe <source> (see
page 601)
:TRIGger:SPI:SOURce:F
RAMe? (see page 601)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<n> ::= 1-2 or 1-4 in NR1 format
