Commands by Subsystem 5
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 585
:TRIGger:SEQuence Commands
Table 88 :TRIGger:SEQuence Commands Summary
Command Query Options and Query Returns
:TRIGger:SEQuence:COU
Nt <count> (see
page 586)
:TRIGger:SEQuence:COU
Nt? (see page 586)
<count> ::= integer in NR1 format
:TRIGger:SEQuence:EDG
E{1|2} <source>,
<slope> (see
page 587)
:TRIGger:SEQuence:EDG
E{1|2}? (see
page 587)
<source> ::= {CHANnel<n> |
EXTernal} for the DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<slope> ::= {POSitive | NEGative}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= query returns
"NONE" if edge source is disabled
:TRIGger:SEQuence:FIN
D <value> (see
page 588)
:TRIGger:SEQuence:FIN
D? (see page 588)
<value> ::= {PATTern1,ENTered |
PATTern1,EXITed | EDGE1 |
PATTern1,AND,EDGE1}
:TRIGger:SEQuence:PAT
Tern{1|2} <value>,
<mask> (see page 589)
:TRIGger:SEQuence:PAT
Tern{1|2}? (see
page 589)
<value> ::= integer or <string>
<mask> ::= integer or <string>
<string> ::= "0xnnnnnn" n ::=
{0,..,9 | A,..,F}
:TRIGger:SEQuence:RES
et <value> (see
page 590)
:TRIGger:SEQuence:RES
et? (see page 590)
<value> ::= {NONE |
PATTern1,ENTered |
PATTern1,EXITed | EDGE1 |
PATTern1,AND,EDGE1 |
PATTern2,ENTered |
PATTern2,EXITed | EDGE2 | TIMer}
Values used in find and trigger
stages not available. EDGE2 not
available if EDGE2,COUNt used in
trigger stage.
:TRIGger:SEQuence:TIM
er <time_value> (see
page 591)
:TRIGger:SEQuence:TIM
er? (see page 591)
<time_value> ::= time from 10 ns
to 10 seconds in NR3 format
:TRIGger:SEQuence:TRI
Gger <value> (see
page 592)
:TRIGger:SEQuence:TRI
Gger? (see page 592)
<value> ::= {PATTern2,ENTered |
PATTern2,EXITed | EDGE2 |
PATTern2,AND,EDGE2 | EDGE2,COUNt
| EDGE2,COUNt,NREFind}
