5 Commands by Subsystem
:TRIGger:LIN:PATTern:DATA
(see page 798)
Command Syntax
:TRIGger:LIN:PATTern:DATA <string>
<string> ::= "n" where n ::= 32-bit integer in signed decimal when
<base> = DECimal
<string> ::= "nn...n" where n ::= {0 |1|X|$}when
<base> = BINary
<string> ::= "0xnn...n" where n ::= {0,..,9 | A,..,F |X|$}when
<base> = HEX
The :TRIGger:LIN:PATTern:DATA command specifies the LIN trigger data
pattern searched for in each LIN data field.
Set a <string> bit to "0" or "1" to set the corresponding bit in the data
pattern to low or high, respectively.
Set a <string> bit to "X" to ignore (mask off) that bit in the data pattern.
Use the "$" character to indicate that the value of the corresponding bit
will not be changed (the existing bit value is used).
When <base> = DECimal, the "X" and "$" characters cannot be entered.
When queried, the "$" character is returned when any bits in the pattern
have the value of "X" and <base> = DECimal. When any bits in a given
nibble have the value of "X" and <base> = HEX, the "$" character is
returned for the corresponding nibble.
NOTE
<base> is specified with the :TRIGger:LIN:PATTern:FORMat command. The default <base>
is DECimal.
NOTE
The :TRIGger:LIN:PATTern:DATA command specifies the LIN trigger data pattern used by
the DATA trigger condition. This command is only valid when the automotive CAN and LIN
serial decode option (Option AMS) has been licensed.
NOTE
The length of the trigger data value is determined by the
:TRIGger:LIN:PATTern:DATA:LENGth command.
NOTE
If more bits are sent for <string> than the specified trigger pattern data length, the most
significant bits will be truncated. If the data length size is changed after the <string> is
programmed, the added or deleted bits will be added to or deleted from the least significant
bits.
