556 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
5 Commands by Subsystem
:TRIGger:IIC Commands
Table 85 :TRIGger:IIC Commands Summary
Command Query Options and Query Returns
:TRIGger:IIC:PATTern:
ADDRess <value> (see
page 557)
:TRIGger:IIC:PATTern:
ADDRess? (see
page 557)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:TRIGger:IIC:PATTern:
DATA <value> (see
page 558)
:TRIGger:IIC:PATTern:
DATA? (see page 558)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:TRIGger:IIC:PATTern:
DATa2 <value> (see
page 559)
:TRIGger:IIC:PATTern:
DATa2? (see page 559)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:TRIGger:IIC[:SOURce]
:CLOCk <source> (see
page 560)
:TRIGger:IIC[:SOURce]
:CLOCk? (see
page 560)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 } for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:IIC[:SOURce]
:DATA <source> (see
page 561)
:TRIGger:IIC[:SOURce]
:DATA? (see page 561)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 } for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:IIC:TRIGger:
QUALifier <value>
(see page 562)
:TRIGger:IIC:TRIGger:
QUALifier? (see
page 562)
<value> ::= {EQUal | NOTequal |
LESSthan | GREaterthan}
:TRIGger:IIC:TRIGger[
:TYPE] <type> (see
page 563)
:TRIGger:IIC:TRIGger[
:TYPE]? (see
page 563)
<type> ::= {STARt | STOP | READ7
| READEprom | WRITe7 | WRITe10 |
NACKnowledge | ANACknowledge |
R7Data2 | W7Data2 | RESTart}
