Commands by Subsystem 5
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 539
:TRIGger:I2S:SOURce:C
LOCk <source> (see
page 549)
:TRIGger:I2S:SOURce:C
LOCk? (see page 549)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 } for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:I2S:SOURce:D
ATA <source> (see
page 550)
:TRIGger:I2S:SOURce:D
ATA? (see page 550)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 } for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:I2S:SOURce:W
SELect <source> (see
page 551)
:TRIGger:I2S:SOURce:W
SELect? (see
page 551)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 } for MSO
models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:I2S:TRIGger
<operator> (see
page 552)
:TRIGger:I2S:TRIGger?
(see page 552)
<operator> ::= {EQUal | NOTequal
| LESSthan | GREaterthan |
INRange | OUTRange | INCReasing |
DECReasing}
:TRIGger:I2S:TWIDth
<word_size> (see
page 554)
:TRIGger:I2S:TWIDth?
(see page 554)
<word_size> ::= 4-32 in NR1
format
:TRIGger:I2S:WSLow
<low_def> (see
page 555)
:TRIGger:I2S:WSLow?
(see page 555)
<low_def> ::= {LEFT | RIGHt}
Table 84 :TRIGger:I2S Commands Summary (continued)
Command Query Options and Query Returns
