538 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
5 Commands by Subsystem
:TRIGger:I2S Commands
Table 84 :TRIGger:I2S Commands Summary
Command Query Options and Query Returns
:TRIGger:I2S:ALIGnmen
t <setting> (see
page 540)
:TRIGger:I2S:ALIGnmen
t? (see page 540)
<setting> ::= {I2S | LJ | RJ}
:TRIGger:I2S:AUDio
<audio_ch> (see
page 541)
:TRIGger:I2S:AUDio?
(see page 541)
<audio_ch> ::= {RIGHt | LEFT |
EITHer}
:TRIGger:I2S:CLOCk:SL
OPe <slope> (see
page 542)
:TRIGger:I2S:CLOCk:SL
OPe? (see page 542)
<slope> ::= {NEGative | POSitive}
:TRIGger:I2S:PATTern:
DATA <string> (see
page 543)
:TRIGger:I2S:PATTern:
DATA? (see page 544)
<string> ::= "n" where n ::=
32-bit integer in signed decimal
when <base> = DECimal
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $} when <base> =
BINary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
:TRIGger:I2S:PATTern:
FORMat <base> (see
page 545)
:TRIGger:I2S:PATTern:
FORMat? (see
page 545)
<base> ::= {BINary | HEX |
DECimal}
:TRIGger:I2S:RANGe
<upper>,<lower> (see
page 546)
:TRIGger:I2S:RANGe?
(see page 546)
<upper> ::= 32-bit integer in
signed decimal, <nondecimal>, or
<string>
<lower> ::= 32-bit integer in
signed decimal, <nondecimal>, or
<string>
<nondecimal> ::= #Hnn...n where n
::= {0,..,9 | A,..,F} for
hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F} for
hexadecimal
:TRIGger:I2S:RWIDth
<receiver> (see
page 548)
:TRIGger:I2S:RWIDth?
(see page 548)
<receiver> ::= 4-32 in NR1 format
