:TRIGger:FLEXray Commands
Table 82 :TRIGger:FLEXray Commands Summary
Command Query Options and Query Returns
:TRIGger:FLEXray:AUTo
setup (see page 518)
n/a n/a
:TRIGger:FLEXray:BAUD
rate <baudrate> (see
page 519)
:TRIGger:FLEXray:BAUD
rate? (see page 519)
<baudrate> ::= {2500000 | 5000000
| 10000000}
:TRIGger:FLEXray:CHAN
nel <channel> (see
page 520)
:TRIGger:FLEXray:CHAN
nel? (see page 520)
<channel> ::= {A | B}
:TRIGger:FLEXray:ERRo
r:TYPE <error_type>
(see page 521)
:TRIGger:FLEXray:ERRo
r:TYPE? (see
page 521)
<error_type> ::= {ALL | HCRC |
FCRC}
:TRIGger:FLEXray:EVEN
t:TYPE <event> (see
page 522)
:TRIGger:FLEXray:EVEN
t:TYPE? (see
page 522)
<event> ::= {WAKeup | TSS | {FES
| DTS} | BSS}
:TRIGger:FLEXray:FRAM
e:CCBase
<cycle_count_base>
(see page 523)
:TRIGger:FLEXray:FRAM
e:CCBase? (see
page 523)
<cycle_count_base> ::= integer
from 0-63
:TRIGger:FLEXray:FRAM
e:CCRepetition
<cycle_count_repetiti
on> (see page 524)
:TRIGger:FLEXray:FRAM
e:CCRepetition? (see
page 524)
<cycle_count_repetition> ::=
{ALL | <rep #>}
<rep #> ::= integer from 2-64
:TRIGger:FLEXray:FRAM
e:ID <frame_id> (see
page 525)
:TRIGger:FLEXray:FRAM
e:ID? (see page 525)
<frame_id> ::= {ALL | <frame #>}
<frame #> ::= integer from 1-2047
:TRIGger:FLEXray:FRAM
e:TYPE <frame_type>
(see page 526)
:TRIGger:FLEXray:FRAM
e:TYPE? (see
page 526)
<frame_type> ::= {NORMal |
STARtup | NULL | SYNC | NSTArtup
| NNULl | NSYNc | ALL}
:TRIGger:FLEXray:SOUR
ce <source> (see
page 527)
:TRIGger:FLEXray:SOUR
ce? (see page 527)
<source> ::= {CHANnel<n>}
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:FLEXray:TRIG
ger <condition> (see
page 528)
:TRIGger:FLEXray:TRIG
ger? (see page 528)
<condition> ::= {FRAMe | ERRor |
EVENt}
