Commands by Subsystem 5
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 511
:TRIGger[:EDGE] Commands
Table 81 :TRIGger[:EDGE] Commands Summary
Command Query Options and Query Returns
:TRIGger[:EDGE]:COUPl
ing {AC | DC | LF}
(see page 512)
:TRIGger[:EDGE]:COUPl
ing? (see page 512)
{AC | DC | LF}
:TRIGger[:EDGE]:LEVel
<level> [,<source>]
(see page 513)
:TRIGger[:EDGE]:LEVel
? [<source>] (see
page 513)
For internal triggers, <level>
::= .75 x full-scale voltage from
center screen in NR3 format.
For external triggers, <level>
::= ±(external range setting) in
NR3 format.
For digital channels (MSO
models), <level> ::= ±8 V.
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 | EXTernal
} for MSO models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger[:EDGE]:REJec
t {OFF | LF | HF}
(see page 514)
:TRIGger[:EDGE]:REJec
t? (see page 514)
{OFF | LF | HF}
:TRIGger[:EDGE]:SLOPe
<polarity> (see
page 515)
:TRIGger[:EDGE]:SLOPe
? (see page 515)
<polarity> ::= {POSitive |
NEGative | EITHer | ALTernate}
:TRIGger[:EDGE]:SOURc
e <source> (see
page 516)
:TRIGger[:EDGE]:SOURc
e? (see page 516)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 |
EXTernal} for MSO models
<n> ::= 1-2 or 1-4 in NR1 format
