:TIMebase Commands
Control all horizontal sweep functions. See "Introduction to :TIMebase
Commands" on page 468.
Table 76 :TIMebase Commands Summary
Command Query Options and Query Returns
:TIMebase:MODE
<value> (see
page 469)
:TIMebase:MODE? (see
page 469)
<value> ::= {MAIN | WINDow | XY |
ROLL}
:TIMebase:POSition
<pos> (see page 470)
:TIMebase:POSition?
(see page 470)
<pos> ::= time from the trigger
event to the display reference
point in NR3 format
:TIMebase:RANGe
<range_value> (see
page 471)
:TIMebase:RANGe? (see
page 471)
<range_value> ::= 5 ns through
500 s in NR3 format
:TIMebase:REFClock
{{0 | OFF} | {1 |
ON}} (see page 472)
:TIMebase:REFClock?
(see page 472)
{0 | 1}
:TIMebase:REFerence
{LEFT | CENTer |
RIGHt} (see page 473)
:TIMebase:REFerence?
(see page 473)
<return_value> ::= {LEFT | CENTer
| RIGHt}
:TIMebase:SCALe
<scale_value> (see
page 474)
:TIMebase:SCALe? (see
page 474)
<scale_value> ::= scale value in
seconds in NR3 format
:TIMebase:VERNier {{0
| OFF} | {1 | ON}}
(see page 475)
:TIMebase:VERNier?
(see page 475)
{0 | 1}
:TIMebase:WINDow:POSi
tion <pos> (see
page 476)
:TIMebase:WINDow:POSi
tion? (see page 476)
<pos> ::= time from the trigger
event to the zoomed view
reference point in NR3 format
:TIMebase:WINDow:RANG
e <range_value> (see
page 477)
:TIMebase:WINDow:RANG
e? (see page 477)
<range value> ::= range value in
seconds in NR3 format for the
zoomed window
:TIMebase:WINDow:SCAL
e <scale_value> (see
page 478)
:TIMebase:WINDow:SCAL
e? (see page 478)
<scale_value> ::= scale value in
seconds in NR3 format for the
zoomed window
