Technical data
Table Of Contents
- In This Book
- Contents
- What's New
- What's New in Version 6.00
- What's New in Version 5.25
- What's New in Version 5.20
- What's New in Version 5.15
- What's New in Version 5.10
- What's New in Version 5.00
- What's New in Version 4.10
- What's New in Version 4.00
- What's New in Version 3.50
- What's New in Version 3.00
- Command Differences From 54620/54640 Series Oscilloscopes
- Setting Up
- Getting Started
- Basic Oscilloscope Program Structure
- Programming the Oscilloscope
- Referencing the IO Library
- Opening the Oscilloscope Connection via the IO Library
- Initializing the Interface and the Oscilloscope
- Using :AUToscale to Automate Oscilloscope Setup
- Using Other Oscilloscope Setup Commands
- Capturing Data with the :DIGitize Command
- Reading Query Responses from the Oscilloscope
- Reading Query Results into String Variables
- Reading Query Results into Numeric Variables
- Reading Definite-Length Block Query Response Data
- Sending Multiple Queries and Reading Results
- Checking Instrument Status
- Other Ways of Sending Commands
- Commands Quick Reference
- Commands by Subsystem
- Common (*) Commands
- *CLS (Clear Status)
- *ESE (Standard Event Status Enable)
- *ESR (Standard Event Status Register)
- *IDN (Identification Number)
- *LRN (Learn Device Setup)
- *OPC (Operation Complete)
- *OPT (Option Identification)
- *RCL (Recall)
- *RST (Reset)
- *SAV (Save)
- *SRE (Service Request Enable)
- *STB (Read Status Byte)
- *TRG (Trigger)
- *TST (Self Test)
- *WAI (Wait To Continue)
- Root (:) Commands
- :ACTivity
- :AER (Arm Event Register)
- :AUToscale
- :AUToscale:AMODE
- :AUToscale:CHANnels
- :BLANk
- :CDISplay
- :DIGitize
- :HWEenable (Hardware Event Enable Register)
- :HWERegister:CONDition (Hardware Event Condition Register)
- :HWERegister[:EVENt] (Hardware Event Event Register)
- :MERGe
- :MTEenable (Mask Test Event Enable Register)
- :MTERegister[:EVENt] (Mask Test Event Event Register)
- :OPEE (Operation Status Enable Register)
- :OPERegister:CONDition (Operation Status Condition Register)
- :OPERegister[:EVENt] (Operation Status Event Register)
- :OVLenable (Overload Event Enable Register)
- :OVLRegister (Overload Event Register)
- :RUN
- :SERial
- :SINGle
- :STATus
- :STOP
- :TER (Trigger Event Register)
- :VIEW
- :ACQuire Commands
- :BUS
Commands - :CALibrate Commands
- :CHANnel
Commands - :DIGital
Commands - :DISPlay Commands
- :EXTernal Trigger Commands
- :FUNCtion Commands
- :HARDcopy Commands
- :LISTer Commands
- :MARKer Commands
- :MEASure Commands
- :MEASure:CLEar
- :MEASure:COUNter
- :MEASure:DEFine
- :MEASure:DELay
- :MEASure:DUTYcycle
- :MEASure:FALLtime
- :MEASure:FREQuency
- :MEASure:NWIDth
- :MEASure:OVERshoot
- :MEASure:PERiod
- :MEASure:PHASe
- :MEASure:PREShoot
- :MEASure:PWIDth
- :MEASure:RESults
- :MEASure:RISetime
- :MEASure:SDEViation
- :MEASure:SHOW
- :MEASure:SOURce
- :MEASure:STATistics
- :MEASure:STATistics:INCRement
- :MEASure:STATistics:RESet
- :MEASure:TEDGe
- :MEASure:TVALue
- :MEASure:VAMPlitude
- :MEASure:VAVerage
- :MEASure:VBASe
- :MEASure:VMAX
- :MEASure:VMIN
- :MEASure:VPP
- :MEASure:VRATio
- :MEASure:VRMS
- :MEASure:VTIMe
- :MEASure:VTOP
- :MEASure:XMAX
- :MEASure:XMIN
- :MTESt Commands
- :MTESt:AMASk:CREate
- :MTESt:AMASk:SOURce
- :MTESt:AMASk:UNITs
- :MTESt:AMASk:XDELta
- :MTESt:AMASk:YDELta
- :MTESt:COUNt:FWAVeforms
- :MTESt:COUNt:RESet
- :MTESt:COUNt:TIME
- :MTESt:COUNt:WAVeforms
- :MTESt:DATA
- :MTESt:DELete
- :MTESt:ENABle
- :MTESt:LOCK
- :MTESt:OUTPut
- :MTESt:RMODe
- :MTESt:RMODe:FACTion:MEASure
- :MTESt:RMODe:FACTion:PRINt
- :MTESt:RMODe:FACTion:SAVE
- :MTESt:RMODe:FACTion:STOP
- :MTESt:RMODe:SIGMa
- :MTESt:RMODe:TIME
- :MTESt:RMODe:WAVeforms
- :MTESt:SCALe:BIND
- :MTESt:SCALe:X1
- :MTESt:SCALe:XDELta
- :MTESt:SCALe:Y1
- :MTESt:SCALe:Y2
- :MTESt:SOURce
- :MTESt:TITLe
- :POD Commands
- :RECall Commands
- :SAVE Commands
- :SBUS Commands
- :SBUS:CAN:COUNt:ERRor
- :SBUS:CAN:COUNt:OVERload
- :SBUS:CAN:COUNt:RESet
- :SBUS:CAN:COUNt:TOTal
- :SBUS:CAN:COUNt:UTILization
- :SBUS:DISPlay
- :SBUS:FLEXray:COUNt:NULL
- :SBUS:FLEXray:COUNt:RESet
- :SBUS:FLEXray:COUNt:SYNC
- :SBUS:FLEXray:COUNt:TOTal
- :SBUS:I2S:BASE
- :SBUS:IIC:ASIZe
- :SBUS:LIN:PARity
- :SBUS:M1553:BASE
- :SBUS:MODE
- :SBUS:SPI:BITorder
- :SBUS:SPI:WIDTh
- :SBUS:UART:BASE
- :SBUS:UART:COUNt:ERRor
- :SBUS:UART:COUNt:RESet
- :SBUS:UART:COUNt:RXFRames
- :SBUS:UART:COUNt:TXFRames
- :SBUS:UART:FRAMing
- :SYSTem Commands
- :TIMebase Commands
- :TRIGger Commands
- General :TRIGger Commands
- :TRIGger:HFReject
- :TRIGger:HOLDoff
- :TRIGger:MODE
- :TRIGger:NREJect
- :TRIGger:PATTern
- :TRIGger:SWEep
- :TRIGger:CAN Commands
- :TRIGger:CAN:PATTern:DATA
- :TRIGger:CAN:PATTern:DATA:LENGth
- :TRIGger:CAN:PATTern:ID
- :TRIGger:CAN:PATTern:ID:MODE
- :TRIGger:CAN:SAMPlepoint
- :TRIGger:CAN:SIGNal:BAUDrate
- :TRIGger:CAN:SOURce
- :TRIGger:CAN:TRIGger
- :TRIGger:DURation Commands
- :TRIGger:DURation:GREaterthan
- :TRIGger:DURation:LESSthan
- :TRIGger:DURation:PATTern
- :TRIGger:DURation:QUALifier
- :TRIGger:DURation:RANGe
- :TRIGger:EBURst Commands
- :TRIGger:EBURst:COUNt
- :TRIGger:EBURst:IDLE
- :TRIGger:EBURst:SLOPe
- :TRIGger[:EDGE] Commands
- :TRIGger[:EDGE]:COUPling
- :TRIGger[:EDGE]:LEVel
- :TRIGger[:EDGE]:REJect
- :TRIGger[:EDGE]:SLOPe
- :TRIGger[:EDGE]:SOURce
- :TRIGger:FLEXray Commands
- :TRIGger:FLEXray:AUTosetup
- :TRIGger:FLEXray:BAUDrate
- :TRIGger:FLEXray:CHANnel
- :TRIGger:FLEXray:ERRor:TYPE
- :TRIGger:FLEXray:EVENt:TYPE
- :TRIGger:FLEXray:FRAMe:CCBase
- :TRIGger:FLEXray:FRAMe:CCRepetition
- :TRIGger:FLEXray:FRAMe:ID
- :TRIGger:FLEXray:FRAMe:TYPE
- :TRIGger:FLEXray:SOURce
- :TRIGger:FLEXray:TRIGger
- :TRIGger:GLITch Commands
- :TRIGger:GLITch:GREaterthan
- :TRIGger:GLITch:LESSthan
- :TRIGger:GLITch:LEVel
- :TRIGger:GLITch:POLarity
- :TRIGger:GLITch:QUALifier
- :TRIGger:GLITch:RANGe
- :TRIGger:GLITch:SOURce
- :TRIGger:I2S Commands
- :TRIGger:I2S:ALIGnment
- :TRIGger:I2S:AUDio
- :TRIGger:I2S:CLOCk:SLOPe
- :TRIGger:I2S:PATTern:DATA
- :TRIGger:I2S:PATTern:FORMat
- :TRIGger:I2S:RANGe
- :TRIGger:I2S:RWIDth
- :TRIGger:I2S:SOURce:CLOCk
- :TRIGger:I2S:SOURce:DATA
- :TRIGger:I2S:SOURce:WSELect
- :TRIGger:I2S:TRIGger
- :TRIGger:I2S:TWIDth
- :TRIGger:I2S:WSLow
- :TRIGger:IIC Commands
- :TRIGger:IIC:PATTern:ADDRess
- :TRIGger:IIC:PATTern:DATA
- :TRIGger:IIC:PATTern:DATa2
- :TRIGger:IIC[:SOURce]:CLOCk
- :TRIGger:IIC[:SOURce]:DATA
- :TRIGger:IIC:TRIGger:QUALifier
- :TRIGger:IIC:TRIGger[:TYPE]
- :TRIGger:LIN Commands
- :TRIGger:LIN:ID
- :TRIGger:LIN:PATTern:DATA
- :TRIGger:LIN:PATTern:DATA:LENGth
- :TRIGger:LIN:PATTern:FORMat
- :TRIGger:LIN:SAMPlepoint
- :TRIGger:LIN:SIGNal:BAUDrate
- :TRIGger:LIN:SOURce
- :TRIGger:LIN:STANdard
- :TRIGger:LIN:SYNCbreak
- :TRIGger:LIN:TRIGger
- :TRIGger:M1553 Commands
- :TRIGger:M1553:AUTosetup
- :TRIGger:M1553:PATTern:DATA
- :TRIGger:M1553:RTA
- :TRIGger:M1553:SOURce:LOWer
- :TRIGger:M1553:SOURce:UPPer
- :TRIGger:M1553:TYPE
- :TRIGger:SEQuence Commands
- :TRIGger:SEQuence:COUNt
- :TRIGger:SEQuence:EDGE
- :TRIGger:SEQuence:FIND
- :TRIGger:SEQuence:PATTern
- :TRIGger:SEQuence:RESet
- :TRIGger:SEQuence:TIMer
- :TRIGger:SEQuence:TRIGger
- :TRIGger:SPI Commands
- :TRIGger:SPI:CLOCk:SLOPe
- :TRIGger:SPI:CLOCk:TIMeout
- :TRIGger:SPI:FRAMing
- :TRIGger:SPI:PATTern:DATA
- :TRIGger:SPI:PATTern:WIDTh
- :TRIGger:SPI:SOURce:CLOCk
- :TRIGger:SPI:SOURce:DATA
- :TRIGger:SPI:SOURce:FRAMe
- :TRIGger:TV Commands
- :TRIGger:TV:LINE
- :TRIGger:TV:MODE
- :TRIGger:TV:POLarity
- :TRIGger:TV:SOURce
- :TRIGger:TV:STANdard
- :TRIGger:UART Commands
- :TRIGger:UART:BASE
- :TRIGger:UART:BAUDrate
- :TRIGger:UART:BITorder
- :TRIGger:UART:BURSt
- :TRIGger:UART:DATA
- :TRIGger:UART:IDLE
- :TRIGger:UART:PARity
- :TRIGger:UART:POLarity
- :TRIGger:UART:QUALifier
- :TRIGger:UART:SOURce:RX
- :TRIGger:UART:SOURce:TX
- :TRIGger:UART:TYPE
- :TRIGger:UART:WIDTh
- :TRIGger:USB Commands
- :TRIGger:USB:SOURce:DMINus
- :TRIGger:USB:SOURce:DPLus
- :TRIGger:USB:SPEed
- :TRIGger:USB:TRIGger
- :WAVeform Commands
- :WAVeform:BYTeorder
- :WAVeform:COUNt
- :WAVeform:DATA
- :WAVeform:FORMat
- :WAVeform:POINts
- :WAVeform:POINts:MODE
- :WAVeform:PREamble
- :WAVeform:SEGMented:COUNt
- :WAVeform:SEGMented:TTAG
- :WAVeform:SOURce
- :WAVeform:SOURce:SUBSource
- :WAVeform:TYPE
- :WAVeform:UNSigned
- :WAVeform:VIEW
- :WAVeform:XINCrement
- :WAVeform:XORigin
- :WAVeform:XREFerence
- :WAVeform:YINCrement
- :WAVeform:YORigin
- :WAVeform:YREFerence
- Common (*) Commands
- Commands A-Z
- Obsolete and Discontinued Commands
- :CHANnel:ACTivity
- :CHANnel:LABel
- :CHANnel:THReshold
- :CHANnel2:SKEW
- :CHANnel
:INPut - :CHANnel
:PMODe - :DISPlay:CONNect
- :DISPlay:ORDer
- :ERASe
- :EXTernal:INPut
- :EXTernal:PMODe
- :FUNCtion:SOURce
- :FUNCtion:VIEW
- :HARDcopy:DESTination
- :HARDcopy:DEVice
- :HARDcopy:FILename
- :HARDcopy:FORMat
- :HARDcopy:GRAYscale
- :HARDcopy:IGColors
- :HARDcopy:PDRiver
- :MEASure:LOWer
- :MEASure:SCRatch
- :MEASure:TDELta
- :MEASure:THResholds
- :MEASure:TMAX
- :MEASure:TMIN
- :MEASure:TSTArt
- :MEASure:TSTOp
- :MEASure:TVOLt
- :MEASure:UPPer
- :MEASure:VDELta
- :MEASure:VSTArt
- :MEASure:VSTOp
- :MTESt:AMASk:{SAVE | STORe}
- :MTESt:AVERage
- :MTESt:AVERage:COUNt
- :MTESt:LOAD
- :MTESt:RUMode
- :MTESt:RUMode:SOFailure
- :MTESt:{STARt | STOP}
- :MTESt:TRIGger:SOURce
- :PRINt?
- :TIMebase:DELay
- :TRIGger:CAN:ACKNowledge
- :TRIGger:CAN:SIGNal:DEFinition
- :TRIGger:LIN:SIGNal:DEFinition
- :TRIGger:THReshold
- :TRIGger:TV:TVMode
- Error Messages
- Status Reporting
- Status Reporting Data Structures
- Status Byte Register (STB)
- Service Request Enable Register (SRE)
- Trigger Event Register (TER)
- Output Queue
- Message Queue
- (Standard) Event Status Register (ESR)
- (Standard) Event Status Enable Register (ESE)
- Error Queue
- Operation Status Event Register (:OPERegister[:EVENt])
- Operation Status Condition Register (:OPERegister:CONDition)
- Arm Event Register (AER)
- Overload Event Register (:OVLRegister)
- Hardware Event Event Register (:HWERegister[:EVENt])
- Hardware Event Condition Register (:HWERegister:CONDition)
- Mask Test Event Event Register (:MTERegister[:EVENt])
- Clearing Registers and Queues
- Status Reporting Decision Chart
- Synchronizing Acquisitions
- More About Oscilloscope Commands
- Programming Examples
- Index
What's New 1
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 45
:OVLRegister (see page 183) The Overload Event Register is now a 16-bit
register (instead of 8-bit) and it contains bits
that identify when faults occur on the
oscilloscope channels (in addition to the bits
that identify when overloads occur).
:PRINt (see page 185) The options are now: COLor (instead of HIRes),
GRAYscale (instead of LORes), PRINter0
(instead of PARallel), BMP8bit (instead of
TIFF). (The PCL option is now invalid.)
*RCL (Recall) (see page 139) The number of instrument state locations is 10
(instead of 3 for the 54620 Series oscilloscopes
or 4 for the 54640 Series oscilloscopes).
*SAV (Save) (see page 143) The number of instrument state locations is 10
(instead of 3 for the 54620 Series oscilloscopes
or 4 for the 54640 Series oscilloscopes).
*TRG (Trigger) (see page 148) The *TRG has the same effect as the :DIGitize
command with no parameters (instead of the
:RUN command).
:TRIGger:TV:MODE (see page 604)The modes have been renamed (however, old
forms of the mode names are still accepted).
:TRIGger:TV:STANdard (see page 607) The P480L60HZ, P720L60HZ, P1080L24HZ,
P1080L25HZ, I1080L50HZ, and I1080L60HZ
standards are supported (in addition to
GENeric, NTSC, PALM, PAL, and SECam).
:VIEW (see page 192) The number of pixel memory locations is 10
(instead of 3).
:WAVeform:COUNt? (see page 637) The count can be any value from 1 to 65536
(instead of 16383).
:WAVeform:POINts (see page 641) There is a new RAW "number of points" option
for retrieving the raw acquisition record data.
Also the maximum number of points that can
be retrieved from the normal measurement
record is 1000 (instead of 2000).
:WAVeform:PREamble (see page 645) The xincrement format is 64-bit floating point
NR3 (instead of 32-bit), and the yreference
format is 32-bit NR1 (instead of 16-bit).
:WAVeform:XINCrement (see page 658) The x-increment value from the preamble is
returned in 64-bit (instead of 32-bit) floating
point NR3 format.
:WAVeform:YREFerence (see page 663) The y-reference value from the preamble is
returned in 32-bit (instead of 16-bit) NR1
format.
Command Differences From 5462x/4x Oscilloscopes
