1 What's New
Changed
Commands
:TRIGger:EBURst:COUNt (see page 508) Sets the Nth edge of burst edge counter
resource.
:TRIGger:EBURst:IDLE (see page 509) Sets the Nth edge in a burst idle resource.
:TRIGger:EBURst:SLOPe (see page 508) Specifies whether the rising edge (POSitive) or
falling edge (NEGative) of the Nth edge in a
burst will generate a trigger.
:TRIGger:IIC:PATTern:DATa2 (see page 559)Sets IIC data 2.
:WAVeform:POINts:MODE (see page 643) Sets the waveform points mode.
Command Description
Command Differences
:ACQuire:TYPE (see page 208) The HRESolution type has been added for
smoothing at slower sweep speeds.
:BLANk (see page 160) Now, you can also use this command with the
serial decode bus.
:DIGitize (see page 162) Now, you can also use this command with the
serial decode bus.
:DISPlay:DATA (see page 259) Now, the PNG format is supported in the query.
:HARDcopy:FORMat (see page 721) Now, the PNG, ASCiixy, and BINary formats are
also supported.
:PRINt (see page 185) Now, the PNG option is supported
:STATus (see page 189) Now, you can also use this command with the
serial decode bus.
:TRIGger:IIC:TRIGger[:TYPE] (see page 563) The ANACknowledge, R7Data2, and W7Data2
types have been added.
:TRIGger:MODE (see page 485) The EBURst mode has been added.
:TRIGger:SEQuence:TRIGger (see page 592) The EDGE2,COUNt,NREFind (no re-find) option
has been added.
:VIEW (see page 192) Now, you can now use this command with the
serial decode bus.
:WAVeform:POINts (see page 641) Now, you can set from 2000 to 8,000,000 points
(in 1-2-5 sequence) when the waveform points
mode is MAXimum or RAW.
:WAVeform:SOURce (see page 650) Now, you can also use this command with the
serial decode bus.
:WAVeform:TYPE (see page 655) The HRESolution type has been added for
smoothing at slower sweep speeds.
