418 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
5 Commands by Subsystem
:SAVE:IMAGe[:STARt]
(see page 798)
Command Syntax
:SAVE:IMAGe[:STARt] [<file_spec>]
<file_spec> ::= {<internal_loc> | <file_name>}
<internal_loc> ::= 0-9; an integer in NR1 format
<file_name> ::= quoted ASCII string
The :SAVE:IMAGe[:STARt] command saves an image.
See Also • "Introduction to :SAVE Commands" on page 416
• ":SAVE:IMAGe:AREA" on page 419
• ":SAVE:IMAGe:FACTors" on page 420
• ":SAVE:IMAGe:FORMat" on page 421
• ":SAVE:IMAGe:INKSaver" on page 422
• ":SAVE:IMAGe:PALette" on page 423
• ":SAVE:FILename" on page 417
• ":RECall:IMAGe[:STARt]" on page 411
NOTE
If a file extension is provided as part of a specified <file_name>, and it does not match the
extension expected by the format specified in :SAVE:IMAGe:FORMat, the format will be
changed if the extension is a valid image file extension.
NOTE
If the extension ".bmp" is used and the current :SAVE:IMAGe:FORMat is not BMP or BMP8,
the format will be changed to BMP.
NOTE
When the <internal_loc> option is used, the :SAVE:IMAGe:FORMat will be changed to TIFF.
