What's New 1
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 41
What's New in Version 3.00
New features in version 3.00 of the InfiniiVision 6000 Series oscilloscope
software are:
• The :SBUS command subsystem for controlling serial decode bus
display, mode, and other options.
• The EBURst trigger mode and supporting :TRIGger:EBURst commands.
• The :ACQuire:AALias and :ACQuire:DAALias commands.
• The :WAVeform:POINts:MODE command.
• The :MEASure:SDEViation command.
• The :TIMebase:REFClock command.
• Changes to the :TRIGger:IIC commands.
• Changes to the :TRIGger:SEQuence:TRIGger command.
• Changes to the :ACQuire:TYPE and :WAVeform:TYPE commands to add
HRESolution type.
• Changes to the :BLANk, :DIGitize, :STATus, :VIEW, and
:WAVeform:SOURce commands to include the serial decode bus.
• Changes to the :HARDcopy:FORMat command to support the PNG,
ASCiixy, and BINary format types.
• Changes to the :DISPlay:DATA? query and the :PRINt command to
support the PNG format.
• Changes to the :WAVeform:POINts command to set from 2000 to
8,000,000 points (in 1-2- 5 sequence) when the waveform points mode is
MAXimum or RAW.
More detailed descriptions of the new and changed commands appear
below.
New Commands
Command Description
:ACQuire:AALias? (see page 195) Returns the current state of the oscilloscope's
anti-alias control.
:ACQuire:DAALias (see page 198) Sets the oscilloscope's disable anti-alias mode.
:MEASure:SDEViation (see page 347) Measures the std deviation of a waveform.
:SBUS:DISPlay (see page 439) Controls the decoded serial bus display.
:SBUS:MODE (see page 448) Determines the decode mode for the serial bus.
:SBUS:SPI:WIDTh (see page 450) Determines the number of bits in a word of
decoded data for SPI.
:TIMebase:REFClock (see page 472) Enables or disables the 10 MHz REF BNC
input/output.
