40 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
1 What's New
Changed
Commands
Obsolete
Commands
:TRIGger:LIN:SAMPlepoint (see page 572) Sets the point during the bit time where the bit
level is sampled to determine whether the bit is
dominant or recessive. The sample point
represents the percentage of time between the
beginning of the bit time to the end of the bit
time.
:TRIGger:LIN:STANdard (see page 575) Sets the LIN standard in effect for triggering
and decoding to be LIN1.3 or LIN2.0.
:TRIGger:LIN:SYNCbreak (see page 576) Sets the length of the LIN sync break to be
greater than or equal to 11,12, or 13 clock
lengths. The sync break is the idle period in the
bus activity at the beginning of each packet
that distinguishes one information packet from
the previous one.
:HWEenable (see page 164) Sets or reads the hardware event enable mask
register.
:HWERegister:CONDition? (see page 166) Queries the hardware event condition register.
:HWERegister[:EVENt]? (see page 168) Queries the hardware event event register.
Command Description
Command Differences
:SBUS:MODE (see page 448) The CAN and LIN serial bus decode modes
have been added.
:TRIGger:CAN:TRIGger (see page 499) The ALLerrors, OVERload, and ACKerror
options have been added.
:TRIGger:LIN:TRIGger (see page 577) The ID (for Frame Id) option has been added.
Obsolete Command Current Command Equivalent Behavior Differences
:TRIGger:CAN:SIGNal:DEFiniti
on (see page 751)
none
:TRIGger:LIN:SIGNal:DEFinitio
n (see page 752)
none
