What's New 1
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 39
What's New in Version 3.50
New features in version 3.50 of the InfiniiVision 6000 Series oscilloscope
software are:
• The CAN and LIN options have been added to the :SBUS:MODE (serial
decode mode) command.
• The :SBUS:CAN:COUNt commands have been added to count CAN bus
frames, count load utilization, and reset the counters.
• The ALLerrors, OVERload, and ACKerror options have been added to
the :TRIGger:CAN:TRIGger command.
• The :TRIGger:LIN:ID, :TRIGger:LIN:SAMPlepoint, :TRIGger:LIN:STANdard,
and :TRIGger:LIN:SYNCbreak commands have been added.
• The :SBUS:LIN:PARity command has been added.
• The ID (for Frame Id) option has been added to the
:TRIGger:LIN:TRIGger command.
• The :HWERegister:CONDition, :HWERegister[:EVENt], and :HWE
commands for the hardware event condition, event, and enable registers
have been added.
More detailed descriptions of the new and changed commands appear
below.
New Commands
Command Description
:SBUS:CAN:COUNt:ERRor? (see page 434) Returns the CAN bus error frame count.
:SBUS:CAN:COUNt:OVERload? (see page 434) Returns the CAN bus overload frame count.
:SBUS:CAN:COUNt:RESet (see page 434) Resets the CAN bus counters.
:SBUS:CAN:COUNt:TOTal? (see page 434) Returns the CAN bus total frame count.
:SBUS:CAN:COUNt:UTILization? (see page 434) Returns a percentage showing CAN bus
utilization.
:SBUS:IIC:ASIZe (see page 445) Determines whether the Read/Write bit is
included as the LSB in the display of the IIC
address field of the decode bus.
:SBUS:LIN:PARity (see page 446) Determines whether the parity bits are
included as the most significant bits (MSB) in
the display of the Frame Id field in the LIN
decode bus.
:TRIGger:LIN:ID (see page 567) Defines the LIN identifier searched for in each
CAN message when the LIN trigger mode is set
to frame ID.
