Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 367

:MEASure:VTOP

(see page 798)

Command Syntax

:MEASure:VTOP [<source>]

<source> ::= {CHANnel<n> | FUNCtion | MATH}

<n>::={1|2|3|4}forthefour channel oscilloscope models

<n> ::= {1 | 2} for the two channel oscilloscope models

The :MEASure:VTOP command installs a screen measurement and starts a

waveform top value measurement.

Query Syntax

:MEASure:VTOP? [<source>]

The :MEASure:VTOP? query returns the vertical value at the top of the

waveform. The top value of the pulse is normally not the same as the

maximum value.

Return Format

<value> ::= vertical value at the top of the waveform in NR3 format

See Also • "Introduction to :MEASure Commands" on page 324

• ":MEASure:SOURce" on page 349

• ":MEASure:VMAX" on page 361

• ":MEASure:VAMPlitude" on page 358

• ":MEASure:VBASe" on page 360

NOTE

This query is not available if the source is FFT (Fast Fourier Transform).
