316 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
5 Commands by Subsystem
:MARKer:Y2Position
(see page 798)
Command Syntax
:MARKer:Y2Position <position> [suffix]
<position> ::= Y2 cursor position in NR3 format
<suffix> ::= {mV | V | dB}
If the :MARKer:MODE is not currently set to WAVeform (see
":MARKer:MODE" on page 309), the :MARKer:Y1Position command:
• Sets :MARKer:MODE to MANual.
• Sets the Y2 cursor position to the specified value.
When the :MARKer:MODE is set to WAVeform, Y positions cannot be set.
Query Syntax
:MARKer:Y2Position?
The :MARKer:Y2Position? query returns current Y2 cursor position. This is
functionally equivalent to the obsolete :MEASure:VSTOp command/query.
Return Format
<position><NL>
<position> ::= Y2 cursor position in NR3 format
See Also • "Introduction to :MARKer Commands" on page 308
• ":MARKer:MODE" on page 309
• ":MARKer:X1Y1source" on page 311
• ":MARKer:X2Y2source" on page 313
• ":MARKer:Y1Position" on page 315
• ":MEASure:VSTOp" on page 738
NOTE
If the front-panel cursors are off or are set to Binary or Hex Mode, the marker position
values are not defined and an error is generated. Make sure to set :MARKer:MODE to
MANual or WAVeform to put the cursors in the front-panel Normal mode.
