Commands by Subsystem 5
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 311
:MARKer:X1Y1source
(see page 798)
Command Syntax
:MARKer:X1Y1source <source>
<source> ::= {CHANnel<n> | FUNCtion | MATH}
<n>::={1|2|3|4}forthefour channel oscilloscope models
<n> ::= {1 | 2} for the two channel oscilloscope models
The :MARKer:X1Y1source command sets the source for the cursors. The
channel you specify must be enabled for cursors to be displayed. If the
channel or function is not on, an error message is issued.
If the marker mode is not currently WAVeform (see ":MARKer:MODE" on
page 309):
• Sending a :MARKer:X1Y1source command will put the cursors in the
MANual mode.
• Setting the source for one pair of markers (for example, X1Y1) sets the
source for the other (for example, X2Y2).
If the marker mode is currently WAVeform, the X1Y1 source can be set
separate from the X2Y2 source.
If :MARKer:MODE is set to OFF or MANual, setting :MEASure:SOURce to
CHANnel<n>, FUNCtion, or MATH will also set :MARKer:X1Y1source and
:MARKer:X2Y2source to this value.
Query Syntax :MARKer:X1Y1source?
The :MARKer:X1Y1source? query returns the current source for the
cursors. If all channels are off or if :MARKer:MODE is set to OFF, the
query returns NONE.
Return Format
<source><NL>
<source> ::= {CHAN<n> | FUNC | NONE}
See Also • "Introduction to :MARKer Commands" on page 308
• ":MARKer:MODE" on page 309
• ":MARKer:X2Y2source" on page 313
• ":MEASure:SOURce" on page 349
NOTE
MATH is an alias for FUNCtion. The query will return FUNC if the source is FUNCtion or
MATH.
