28 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
1 What's New
Changed
Commands
Obsolete
Commands
Command Differences
:BUS<n>:LABel (see page 217) Labels can now be up to 10 characters.
:CHANnel<n>:LABel (see page 237) Labels can now be up to 10 characters.
:DIGital<n>:LABel (see page 252) Labels can now be up to 10 characters.
:DISPlay:LABList (see page 262) Labels can now be up to 10 characters.
:MARKer:MODE (see page 309) You can now select the WAVeform tracking
cursors mode.
:RECall:PWD (see page 413) You can set the present working directory in
addition to querying for this information.
:SAVE:IMAGe[:STARt] (see page 418) The file extension specified will change the
:SAVE:IMAGe:FORMat setting if it is a valid
image file extension.
:SAVE:PWD (see page 426) You can set the present working directory in
addition to querying for this information.
:SAVE:WAVeform[:STARt] (see page 418) The file extension specified will change the
:SAVE:WAVeform:FORMat setting if it is a valid
waveform file extension.
:TRIGger:CAN:SIGNal:BAUDrate (see
page 497)
The baud rate value can now be set in 100 b/s
increments.
:TRIGger:LIN:SIGNal:BAUDrate (see page 573) The baud rate value can now be set in 100 b/s
increments.
:TRIGger:UART:BAUDrate (see page 611) The baud rate value can now be set in 100 b/s
increments and the maximum baud rate is now
3Mb/s.
:TRIGger:UART:DATA (see page 614) You can now specify the data value using a
quoted ASCII character.
Obsolete Command Current Command Equivalent Behavior Differences
:MTESt:AMASk:{SAVE |
STORe} (see page 739)
:SAVE:MASK[:STARt] (see
page 425)
:MTESt:AVERage (see
page 740)
:ACQuire:TYPE AVERage (see
page 208)
:MTESt:AVERage:COUNt (see
page 741)
:ACQuire:COUNt (see
page 197)
:MTESt:LOAD (see page 742) :RECall:MASK[:STARt] (see
page 412)
:MTESt:RUMode (see
page 743)
:MTESt:RMODe (see
page 389)
