5 Commands by Subsystem
:EXTernal Trigger Commands
Control the input characteristics of the external trigger input. See
"Introduction to :EXTernal Trigger Commands" on page 266.
Introduction to
:EXTernal Trigger
Commands
The EXTernal trigger subsystem commands control the input
characteristics of the external trigger input. The probe factor, impedance,
input range, input protection state, units, and bandwidth limit settings
may all be queried. Depending on the instrument type, some settings may
be changeable.
Reporting the Setup
Use :EXTernal? to query setup information for the EXTernal subsystem.
Return Format
Table 64 :EXTernal Trigger Commands Summary
Command Query Options and Query Returns
:EXTernal:BWLimit
<bwlimit> (see
page 268)
:EXTernal:BWLimit?
(see page 268)
<bwlimit> ::= {0 | OFF}
:EXTernal:IMPedance
<value> (see
page 269)
:EXTernal:IMPedance?
(see page 269)
<impedance> ::= {ONEMeg | FIFTy}
:EXTernal:PROBe
<attenuation> (see
page 270)
:EXTernal:PROBe? (see
page 270)
<attenuation> ::= probe
attenuation ratio in NR3 format
n/a :EXTernal:PROBe:ID?
(see page 271)
<probe id> ::= unquoted ASCII
string up to 11 characters
:EXTernal:PROBe:STYPe
<signal type> (see
page 272)
:EXTernal:PROBe:STYPe
? (see page 272)
<signal type> ::= {DIFFerential |
SINGle}
:EXTernal:PROTection[
:CLEar] (see
page 273)
:EXTernal:PROTection?
(see page 273)
{NORM | TRIP}
:EXTernal:RANGe
<range>[<suffix>]
(see page 274)
:EXTernal:RANGe? (see
page 274)
<range> ::= vertical full-scale
range value in NR3 format
<suffix> ::= {V | mV}
:EXTernal:UNITs
<units> (see
page 275)
:EXTernal:UNITs? (see
page 275)
<units> ::= {VOLT | AMPere}
