:DIGital<n>:THReshold

(see page 798)

Command Syntax

:DIGital<n>:THReshold <value>

<value> ::= {CMOS | ECL | TTL | <user defined value>[<suffix>]}

<user defined value> ::= -8.00 to +8.00 in NR3 format

<suffix> ::= {V | mV | uV}

<n> ::= An integer, 0, 1,..,15, is attached as a suffix to the command

and defines the logic channel that is affected by the command.

• TTL = 1.4V

• CMOS = 2.5V

• ECL = - 1.3V

The :DIGital<n>:THReshold command sets the logic threshold value for all

channels grouped with the specified channel (D0- D7, D8- D15). The

threshold is used for triggering purposes and for displaying the digital

data as high (above the threshold) or low (below the threshold).

Query Syntax

:DIGital<n>:THReshold?

The :DIGital<n>:THReshold? query returns the threshold value for the

specified channel.

Return Format

<value> ::= threshold value in NR3 format

See Also • "Introduction to :DIGital<n> Commands" on page 249

• ":POD<n>:THReshold" on page 407

• ":TRIGger[:EDGE]:LEVel" on page 513

NOTE

This command is only valid for the MSO models.
