What's New 1
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 25
What's New in Version 5.25
New features in version 5.25 of the InfiniiVision 6000 Series oscilloscope
software are:
• The Lister display for showing decoded serial data in tabular format.
• The ability to trigger on and decode I2S serial bus data with a
four-channel oscilloscope that includes the Option SND license.
• FlexRay event triggering.
More detailed descriptions of the new and changed commands appear
below.
New Commands
Command Description
:CHANnel<n>:PROBe:HEAD[:TYPE] (see
page 240)
Sets an analog channel probe head type and dB
value.
:DISPlay:FREeze Freezes the display without stopping currently
running acquisitions.
:LISTer Commands (see page 304) Commands for turning the Lister display on/off
and for returning the Lister data.
:MTESt:RMODe:FACTion:MEASure (see
page 390)
Lets you enable or disable measurements on
mask test failures.
:SAVE:LISTer[:STARt] (see page 424) Saves the Lister display data to a file.
:SBUS:I2S:BASE (see page 444) Determines the base to use for the I2S decode
display.
:TRIGger:FLEXray:EVENt:AUToset Automatically changes oscilloscope settings
for the selected FlexRay event trigger type.
:TRIGger:FLEXray:EVENt:LEVel Lets you fine-tune the voltage level for the
FlexRay event trigger.
:TRIGger:FLEXray:EVENt:SOURce Specifies the FlexRay event trigger source.
:TRIGger:FLEXray:EVENt:TYPE (see page 522) Specifies the FlexRay event type to trigger on.
:TRIGger:I2S Commands (see page 538) Commands for triggering on I2S signals.
:TRIGger:LIN:PATTern:DATA (see page 568) Sets the data value when triggering on a LIN
frame ID and data.
:TRIGger:LIN:PATTern:DATA:LENGth (see
page 570)
Sets the byte length of the LIN data string.
:TRIGger:LIN:PATTern:FORMat (see page 571) Sets the entry (and query) number base used
by the :TRIGger:LIN:PATTern:DATA command.
