230 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
5 Commands by Subsystem
Introduction to
:CHANnel<n>
Commands
<n>::={1|2|3|4}forthefour channel oscilloscope models
<n> ::= {1 | 2} for the two channel oscilloscope models
The CHANnel<n> subsystem commands control an analog channel (vertical
or Y- axis of the oscilloscope). Channels are independently programmable
for all offset, probe, coupling, bandwidth limit, inversion, vernier, and
range (scale) functions. The channel number (1, 2, 3, or 4) specified in the
command selects the analog channel that is affected by the command.
A label command provides identifying annotations of up to 10 characters.
You can toggle the channel displays on and off with the
:CHANnel<n>:DISPlay command as well as with the root level commands
:VIEW and :BLANk.
:CHANnel<n>:PROBe:SKE
W <skew_value> (see
page 242)
:CHANnel<n>:PROBe:SKE
W? (see page 242)
<skew_value> ::= -100 ns to +100
ns in NR3 format
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:PROBe:STY
Pe <signal type> (see
page 243)
:CHANnel<n>:PROBe:STY
Pe? (see page 243)
<signal type> ::= {DIFFerential |
SINGle}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:PROTectio
n (see page 244)
:CHANnel<n>:PROTectio
n? (see page 244)
{NORM | TRIP}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:RANGe
<range>[suffix] (see
page 245)
:CHANnel<n>:RANGe?
(see page 245)
<range> ::= Vertical full-scale
range value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:SCALe
<scale>[suffix] (see
page 246)
:CHANnel<n>:SCALe?
(see page 246)
<scale> ::= Vertical units per
division value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:UNITs
<units> (see
page 247)
:CHANnel<n>:UNITs?
(see page 247)
<units> ::= {VOLT | AMPere}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:VERNier
{{0 | OFF} | {1 |
ON}} (see page 248)
:CHANnel<n>:VERNier?
(see page 248)
{0 | 1}
<n> ::= 1-2 or 1-4 in NR1 format
Table 59 :CHANnel<n> Commands Summary (continued)
Command Query Options and Query Returns
NOTE
The obsolete CHANnel subsystem is supported.
