212 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide

5 Commands by Subsystem

:BUS<n>:BIT<m>

(see page 798)

Command Syntax

:BUS<n>:BIT<m> <display>

<display> ::= {{1 | ON} | {0 | OFF}}

<n> ::= An integer, 1 or 2, is attached as a suffix to BUS

and defines the bus that is affected by the command.

<m> ::= An integer, 0,..,15, is attached as a suffix to BIT

and defines the digital channel that is affected by the command.

The :BUS<n>:BIT<m> command includes or excludes the selected bit as

part of the definition for the selected bus. If the parameter is a 1 (ON),

the bit is included in the definition. If the parameter is a 0 (OFF), the bit

is excluded from the definition. Note: BIT0- 15 correspond to DIGital0- 15.

Query Syntax

:BUS<n>:BIT<m>?

The :BUS<n>:BIT<m>? query returns the value indicating whether the

specified bit is included or excluded from the specified bus definition.

Return Format

<display> ::= {0 | 1}

See Also • "Introduction to :BUS<n> Commands" on page 211

• ":BUS<n>:BITS" on page 213

• ":BUS<n>:CLEar" on page 215

• ":BUS<n>:DISPlay" on page 216

• ":BUS<n>:LABel" on page 217

• ":BUS<n>:MASK" on page 218

Example Code

' Include digital channel 1 in bus 1:

myScope.WriteString ":BUS1:BIT1 ON"

NOTE

This command is only valid for the MSO models.
