:ACQuire:RSIGnal
(see page 798)
Command Syntax
:ACQuire:RSIGnal <ref_signal_mode>
<ref_signal_mode> ::= {OFF | OUT | IN}
The :ACQuire:RSIGnal command selects the 10 MHz reference signal mode.
• The OFF mode disables the oscilloscope's 10 MHz REF BNC connector.
• The OUT mode is used to synchronize the timebase of two or more
instruments.
• The IN mode is used to supply a sample clock to the oscilloscope. A
10 MHz square or sine wave signal is input to the BNC connector
labeled 10 MHz REF. The amplitude must be between 180 mV and 1 V,
with an offset of between 0 V and 2 V.
Query Syntax
:ACQuire:RSIGnal?
The :ACQuire:RSIGnal? query returns the current 10 MHz reference signal
mode.
Return Format
<ref_signal_mode><NL>
<ref_signal_mode> ::= {OFF | OUT | IN}
See Also • ":TIMebase:REFClock" on page 472
• The Agilent InfiniiVision 6000 Series Oscilloscope User's Guide for
information on using the 10 MHz reference clock.
CAUTION
Do not apply more than ±15 V at the 10 MHz REF BNC connector on the rear panel,
or damage to the instrument may occur.
