:ACQuire Commands
Set the parameters for acquiring and storing data. See "Introduction to
:ACQuire Commands" on page 193.
Introduction to
:ACQuire
Commands
The ACQuire subsystem controls the way in which waveforms are
acquired. These acquisition types are available: normal, averaging, peak
detect, and high resolution. Two acquisition modes are available: real- time
mode, and equivalent-time mode.
Table 56 :ACQuire Commands Summary
Command Query Options and Query Returns
n/a :ACQuire:AALias? (see
page 195)
{1 | 0}
:ACQuire:COMPlete
<complete> (see
page 196)
:ACQuire:COMPlete?
(see page 196)
<complete> ::= 100; an integer in
NR1 format
:ACQuire:COUNt
<count> (see
page 197)
:ACQuire:COUNt? (see
page 197)
<count> ::= an integer from 2 to
65536 in NR1 format
:ACQuire:DAALias
<mode> (see page 198)
:ACQuire:DAALias?
(see page 198)
<mode> ::= {DISable | AUTO}
:ACQuire:MODE <mode>
(see page 199)
:ACQuire:MODE? (see
page 199)
<mode> ::= {RTIMe | ETIMe |
SEGMented}
n/a :ACQuire:POINts? (see
page 200)
<# points> ::= an integer in NR1
format
:ACQuire:RSIGnal
<ref_signal_mode>
(see page 201)
:ACQuire:RSIGnal?
(see page 201)
<ref_signal_mode> ::= {OFF | OUT
| IN}
:ACQuire:SEGMented:AN
ALyze (see page 202)
n/a n/a (with Option SGM)
:ACQuire:SEGMented:CO
UNt <count> (see
page 203)
:ACQuire:SEGMented:CO
UNt? (see page 203)
<count> ::= an integer from 2 to
2000 (w/8M memory) in NR1 format
(with Option SGM)
:ACQuire:SEGMented:IN
Dex <index> (see
page 204)
:ACQuire:SEGMented:IN
Dex? (see page 204)
<index> ::= an integer from 2 to
2000 (w/8M memory) in NR1 format
(with Option SGM)
n/a :ACQuire:SRATe? (see
page 207)
<sample_rate> ::= sample rate
(samples/s) in NR3 format
:ACQuire:TYPE <type>
(see page 208)
:ACQuire:TYPE? (see
page 208)
<type> ::= {NORMal | AVERage |
HRESolution | PEAK}
