Introduction to
Root (:)
Commands
Root level commands control many of the basic operations of the
instrument. These commands are always recognized by the parser if they
are prefixed with a colon, regardless of current command tree position.
After executing a root-level command, the parser is positioned at the root
of the command tree.
n/a :OVLRegister? (see
page 183)
<value> ::= integer in NR1
format. See OVLenable for <value>
:PRINt [<options>]
(see page 185)
n/a <options> ::= [<print
option>][,..,<print option>]
<print option> ::= {COLor |
GRAYscale | PRINter0 | BMP8bit |
BMP | PNG | NOFactors | FACTors}
<print option> can be repeated up
to 5 times.
:RUN (see page 186) n/a n/a
n/a :SERial (see
page 187)
<return value> ::= unquoted
string containing serial number
:SINGle (see
page 188)
n/a n/a
n/a :STATus? <display>
(see page 189)
{0 | 1}
<display> ::= {CHANnel<n> |
DIGital0,..,DIGital15 | POD{1 |
2} | BUS{1 | 2} | FUNCtion | MATH
| SBUS}
<n> ::= 1-2 or 1-4 in NR1 format
:STOP (see page 190) n/a n/a
n/a :TER? (see page 191) {0 | 1}
:VIEW <source> (see
page 192)
n/a <source> ::= {CHANnel<n> |
PMEMory{0 | 1 | 2 | 3 | 4 | 5 | 6
| 7 | 8 | 9} | FUNCtion | MATH |
SBUS} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 |
PMEMory{0 | 1 | 2 | 3 | 4 | 5 | 6
| 7 | 8 | 9} | POD{1 | 2} | BUS{1
| 2} | FUNCtion | MATH | SBUS}
for MSO models
<n> ::= 1-2 or 1-4 in NR1 format
Table 45 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
