5 Commands by Subsystem
:DIGitize
[<source>[,..,<source
>]] (see page 162)
n/a <source> ::= {CHANnel<n> |
FUNCtion | MATH | SBUS} for DSO
models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 | POD{1 |
2} | BUS{1 | 2} | FUNCtion | MATH
| SBUS} for MSO models
<source> can be repeated up to 5
times
<n> ::= 1-2 or 1-4 in NR1 format
:HWEenable <n> (see
page 164)
:HWEenable? (see
page 164)
<n> ::= 16-bit integer in NR1
format
n/a :HWERregister:CONDiti
on? (see page 166)
<n> ::= 16-bit integer in NR1
format
n/a :HWERegister[:EVENt]?
(see page 168)
<n> ::= 16-bit integer in NR1
format
:MERGe <pixel memory>
(see page 170)
n/a <pixel memory> ::= {PMEMory{0 | 1
| 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9}}
:MTEenable <n> (see
page 171)
:MTEenable? (see
page 171)
<n> ::= 16-bit integer in NR1
format
n/a :MTERegister[:EVENt]?
(see page 173)
<n> ::= 16-bit integer in NR1
format
:OPEE <n> (see
page 175)
:OPEE? (see page 176) <n> ::= 16-bit integer in NR1
format
n/a :OPERregister:CONDiti
on? (see page 177)
<n> ::= 16-bit integer in NR1
format
n/a :OPERegister[:EVENt]?
(see page 179)
<n> ::= 16-bit integer in NR1
format
:OVLenable <mask>
(see page 181)
:OVLenable? (see
page 182)
<mask> ::= 16-bit integer in NR1
format as shown:
Bit Weight Input
--- ------ ----------
10 1024 Ext Trigger Fault
9 512 Channel 4 Fault
8 256 Channel 3 Fault
7 128 Channel 2 Fault
6 64 Channel 1 Fault
4 16 Ext Trigger OVL
3 8 Channel 4 OVL
2 4 Channel 3 OVL
1 2 Channel 2 OVL
0 1 Channel 1 OVL
Table 45 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
