Root (:) Commands
Control many of the basic functions of the oscilloscope and reside at the
root level of the command tree. See "Introduction to Root (:) Commands"
on page 153.
Table 45 Root (:) Commands Summary
Command Query Options and Query Returns
:ACTivity (see
page 154)
:ACTivity? (see
page 154)
<return value> ::=
<edges>,<levels>
<edges> ::= presence of edges
(32-bit integer in NR1 format)
<levels> ::= logical highs or
lows (32-bit integer in NR1
format)
n/a :AER? (see page 155) {0 | 1}; an integer in NR1 format
:AUToscale
[<source>[,..,<source
>]] (see page 156)
n/a <source> ::= CHANnel<n> for DSO
models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 | POD1 |
POD2} for MSO models
<source> can be repeated up to 5
times
<n> ::= 1-2 or 1-4 in NR1 format
:AUToscale:AMODE
<value> (see
page 158)
:AUToscale:AMODE?
(see page 158)
<value> ::= {NORMal | CURRent}}
:AUToscale:CHANnels
<value> (see
page 159)
:AUToscale:CHANnels?
(see page 159)
<value> ::= {ALL | DISPlayed}}
:BLANk [<source>]
(see page 160)
n/a <source> ::= {CHANnel<n>} |
FUNCtion | MATH | SBUS} for DSO
models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 | POD{1 |
2} | BUS{1 | 2} | FUNCtion | MATH
| SBUS} for MSO models
<n> ::= 1-2 or 1-4 in NR1 format
:CDISplay (see
page 161)
n/a n/a
