114 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:TRIGger:SPI:SOURce:C
LOCk <source> (see
page 599)
:TRIGger:SPI:SOURce:C
LOCk? (see page 599)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:SPI:SOURce:D
ATA <source> (see
page 600)
:TRIGger:SPI:SOURce:D
ATA? (see page 600)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<n> ::= 1-2 or 1-4 in NR1 format
:TRIGger:SPI:SOURce:F
RAMe <source> (see
page 601)
:TRIGger:SPI:SOURce:F
RAMe? (see page 601)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<n> ::= 1-2 or 1-4 in NR1 format
Table 35 :TRIGger:SPI Commands Summary (continued)
Command Query Options and Query Returns
Table 36 :TRIGger:TV Commands Summary
Command Query Options and Query Returns
:TRIGger:TV:LINE
<line number> (see
page 603)
:TRIGger:TV:LINE?
(see page 603)
<line number> ::= integer in NR1
format
:TRIGger:TV:MODE <tv
mode> (see page 604)
:TRIGger:TV:MODE?
(see page 604)
<tv mode> ::= {FIEld1 | FIEld2 |
AFIelds | ALINes | LINE |
VERTical | LFIeld1 | LFIeld2 |
LALTernate | LVERtical}
:TRIGger:TV:POLarity
<polarity> (see
page 605)
:TRIGger:TV:POLarity?
(see page 605)
<polarity> ::= {POSitive |
NEGative}
:TRIGger:TV:SOURce
<source> (see
page 606)
:TRIGger:TV:SOURce?
(see page 606)
<source> ::= {CHANnel<n>}
<n> ::= 1-2 or 1-4 integer in NR1
format
:TRIGger:TV:STANdard
<standard> (see
page 607)
:TRIGger:TV:STANdard?
(see page 607)
<standard> ::= {GENeric | NTSC |
PALM | PAL | SECam | {P480L60HZ |
P480} | {P720L60HZ | P720} |
{P1080L24HZ | P1080} | P1080L25HZ
| P1080L50HZ | P1080L60HZ |
{I1080L50HZ | I1080} |
I1080L60HZ}
