Commands Quick Reference 4
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 113
:TRIGger:SEQuence:RES
et <value> (see
page 590)
:TRIGger:SEQuence:RES
et? (see page 590)
<value> ::= {NONE |
PATTern1,ENTered |
PATTern1,EXITed | EDGE1 |
PATTern1,AND,EDGE1 |
PATTern2,ENTered |
PATTern2,EXITed | EDGE2 | TIMer}
Values used in find and trigger
stages not available. EDGE2 not
available if EDGE2,COUNt used in
trigger stage.
:TRIGger:SEQuence:TIM
er <time_value> (see
page 591)
:TRIGger:SEQuence:TIM
er? (see page 591)
<time_value> ::= time from 10 ns
to 10 seconds in NR3 format
:TRIGger:SEQuence:TRI
Gger <value> (see
page 592)
:TRIGger:SEQuence:TRI
Gger? (see page 592)
<value> ::= {PATTern2,ENTered |
PATTern2,EXITed | EDGE2 |
PATTern2,AND,EDGE2 | EDGE2,COUNt
| EDGE2,COUNt,NREFind}
Table 34 :TRIGger:SEQuence Commands Summary (continued)
Command Query Options and Query Returns
Table 35 :TRIGger:SPI Commands Summary
Command Query Options and Query Returns
:TRIGger:SPI:CLOCk:SL
OPe <slope> (see
page 594)
:TRIGger:SPI:CLOCk:SL
OPe? (see page 594)
<slope> ::= {NEGative | POSitive}
:TRIGger:SPI:CLOCk:TI
Meout <time_value>
(see page 595)
:TRIGger:SPI:CLOCk:TI
Meout? (see page 595)
<time_value> ::= time in seconds
in NR1 format
:TRIGger:SPI:FRAMing
<value> (see
page 596)
:TRIGger:SPI:FRAMing?
(see page 596)
<value> ::= {CHIPselect |
NOTChipselect | TIMeout}
:TRIGger:SPI:PATTern:
DATA <value>, <mask>
(see page 597)
:TRIGger:SPI:PATTern:
DATA? (see page 597)
<value> ::= integer or <string>
<mask> ::= integer or <string>
<string> ::= "0xnnnnnn" where n
::= {0,..,9 | A,..,F}
:TRIGger:SPI:PATTern:
WIDTh <width> (see
page 598)
:TRIGger:SPI:PATTern:
WIDTh? (see page 598)
<width> ::= integer from 4 to 32
in NR1 format
