4 Commands Quick Reference
:TRIGger:M1553:RTA
<value> (see
page 581)
:TRIGger:M1553:RTA?
(see page 581)
<value> ::= 5-bit integer in
decimal, <nondecimal>, or
<string> from 0-31
<nondecimal> ::= #Hnn where n ::=
{0,..,9|A,..,F}
<string> ::= "0xnn" where n::=
{0,..,9|A,..,F}
:TRIGger:M1553:SOURce
:LOWer <source> (see
page 582)
:TRIGger:M1553:SOURce
:LOWer? (see
page 582)
<source> ::= {CHANnel<n>}
<n> ::= {2 | 4}
:TRIGger:M1553:SOURce
:UPPer <source> (see
page 583)
:TRIGger:M1553:SOURce
:UPPer? (see
page 583)
<source> ::= {CHANnel<n>}
<n> ::= {1 | 3}
:TRIGger:M1553:TYPE
<type> (see page 584)
:TRIGger:M1553:TYPE?
(see page 584)
<type> ::= {DSTArt | DSTOp |
CSTArt | CSTOp | RTA | PERRor |
SERRor | MERRor | RTA11}
Table 33 :TRIGger:M1553 Commands Summary (continued)
Command Query Options and Query Returns
Table 34 :TRIGger:SEQuence Commands Summary
Command Query Options and Query Returns
:TRIGger:SEQuence:COU
Nt <count> (see
page 586)
:TRIGger:SEQuence:COU
Nt? (see page 586)
<count> ::= integer in NR1 format
:TRIGger:SEQuence:EDG
E{1|2} <source>,
<slope> (see
page 587)
:TRIGger:SEQuence:EDG
E{1|2}? (see
page 587)
<source> ::= {CHANnel<n> |
EXTernal} for the DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15} for the
MSO models
<slope> ::= {POSitive | NEGative}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= query returns
"NONE" if edge source is disabled
:TRIGger:SEQuence:FIN
D <value> (see
page 588)
:TRIGger:SEQuence:FIN
D? (see page 588)
<value> ::= {PATTern1,ENTered |
PATTern1,EXITed | EDGE1 |
PATTern1,AND,EDGE1}
:TRIGger:SEQuence:PAT
Tern{1|2} <value>,
<mask> (see page 589)
:TRIGger:SEQuence:PAT
Tern{1|2}? (see
page 589)
<value> ::= integer or <string>
<mask> ::= integer or <string>
<string> ::= "0xnnnnnn" n ::=
{0,..,9 | A,..,F}
