100 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
n/a :SBUS:UART:COUNt:TXFR
ames? (see page 455)
<frame_count> ::= integer in NR1
format
:SBUS:UART:FRAMing
<value> (see
page 456)
:SBUS:UART:FRAMing?
(see page 456)
<value> ::= {OFF | <decimal> |
<nondecimal>}
<decimal> ::= 8-bit integer from
0-255 (0x00-0xff)
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
Table 20 :SBUS Commands Summary (continued)
Command Query Options and Query Returns
Table 21 :SYSTem Commands Summary
Command Query Options and Query Returns
:SYSTem:DATE <date>
(see page 458)
:SYSTem:DATE? (see
page 458)
<date> ::= <year>,<month>,<day>
<year> ::= 4-digit year in NR1
format
<month> ::= {1,..,12 | JANuary |
FEBruary | MARch | APRil | MAY |
JUNe | JULy | AUGust | SEPtember
| OCTober | NOVember | DECember}
<day> ::= {1,..31}
:SYSTem:DSP <string>
(see page 459)
n/a <string> ::= up to 254 characters
as a quoted ASCII string
n/a :SYSTem:ERRor? (see
page 460)
<error> ::= an integer error code
<error string> ::= quoted ASCII
string.
See Error Messages (see
page 755).
:SYSTem:LOCK <value>
(see page 461)
:SYSTem:LOCK? (see
page 461)
<value> ::= {{1 | ON} | {0 |
OFF}}
:SYSTem:PRECision
<value> (see
page 462)
:SYSTem:PRECision?
(see page 462)
<value> ::= {{1 | ON} | {0 |
OFF}}
:SYSTem:PROTection:LO
CK <value> (see
page 463)
:SYSTem:PROTection:LO
CK? (see page 463)
<value> ::= {{1 | ON} | {0 |
OFF}}
