Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 99
:SBUS<n>:UART:BITorde
r <bitorder> (see
page 540)
:SBUS<n>:UART:BITorde
r? (see page 540)
<bitorder> ::= {LSBFirst |
MSBFirst}
n/a :SBUS<n>:UART:COUNt:E
RRor? (see page 541)
<frame_count> ::= integer in NR1
format
:SBUS<n>:UART:COUNt:R
ESet (see page 542)
n/a n/a
n/a :SBUS<n>:UART:COUNt:R
XFRames? (see
page 543)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:UART:COUNt:T
XFRames? (see
page 544)
<frame_count> ::= integer in NR1
format
:SBUS<n>:UART:FRAMing
<value> (see
page 545)
:SBUS<n>:UART:FRAMing
? (see page 545)
<value> ::= {OFF | <decimal> |
<nondecimal>}
<decimal> ::= 8-bit integer from
0-255 (0x00-0xff)
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
:SBUS<n>:UART:PARity
<parity> (see
page 546)
:SBUS<n>:UART:PARity?
(see page 546)
<parity> ::= {EVEN | ODD | NONE}
:SBUS<n>:UART:POLarit
y <polarity> (see
page 547)
:SBUS<n>:UART:POLarit
y? (see page 547)
<polarity> ::= {HIGH | LOW}
:SBUS<n>:UART:SOURce:
RX <source> (see
page 548)
:SBUS<n>:UART:SOURce:
RX? (see page 548)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
Table 27 :SBUS<n>:UART Commands Summary (continued)
Command Query Options and Query Returns
