98 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:SPI:SOURce:M
OSI <source> (see
page 528)
:SBUS<n>:SPI:SOURce:M
OSI? (see page 528)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA
<string> (see
page 529)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA?
(see page 529)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:WIDTh
<width> (see
page 530)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:WIDTh?
(see page 530)
<width> ::= integer from 4 to 64
in NR1 format
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:DATA
<string> (see
page 531)
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:DATA?
(see page 531)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:WIDTh
<width> (see
page 532)
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:WIDTh?
(see page 532)
<width> ::= integer from 4 to 64
in NR1 format
:SBUS<n>:SPI:TRIGger:
TYPE <value> (see
page 533)
:SBUS<n>:SPI:TRIGger:
TYPE? (see page 533)
<value> ::= {MOSI | MISO}
:SBUS<n>:SPI:WIDTh
<word_width> (see
page 534)
:SBUS<n>:SPI:WIDTh?
(see page 534)
<word_width> ::= integer 4-16 in
NR1 format
Table 26 :SBUS<n>:SPI Commands Summary (continued)
Command Query Options and Query Returns
Table 27 :SBUS<n>:UART Commands Summary
Command Query Options and Query Returns
:SBUS<n>:UART:BASE
<base> (see page 538)
:SBUS<n>:UART:BASE?
(see page 538)
<base> ::= {ASCii | BINary | HEX}
:SBUS<n>:UART:BAUDrat
e <baudrate> (see
page 539)
:SBUS<n>:UART:BAUDrat
e? (see page 539)
<baudrate> ::= integer from 1200
to 8000000 in 100 b/s increments
