96 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:LIN:SYNCbrea
k <value> (see
page 511)
:SBUS<n>:LIN:SYNCbrea
k? (see page 511)
<value> ::= integer = {11 | 12 |
13}
:SBUS<n>:LIN:TRIGger
<condition> (see
page 512)
:SBUS<n>:LIN:TRIGger?
(see page 512)
<condition> ::= {SYNCbreak | ID |
DATA}
:SBUS<n>:LIN:TRIGger:
ID <value> (see
page 513)
:SBUS<n>:LIN:TRIGger:
ID? (see page 513)
<value> ::= 7-bit integer in
decimal, <nondecimal>, or
<string> from 0-63 or 0x00-0x3f
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F} for hexadecimal
:SBUS<n>:LIN:TRIGger:
PATTern:DATA <string>
(see page 514)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA? (see
page 514)
<string> ::= "n" where n ::=
32-bit integer in signed decimal
when <base> = DECimal
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $} when <base> =
BINary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth
<length> (see
page 516)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth?
(see page 516)
<length> ::= integer from 1 to 8
in NR1 format
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat <base>
(see page 517)
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat? (see
page 517)
<base> ::= {BINary | HEX |
DECimal}
Table 25 :SBUS<n>:LIN Commands Summary (continued)
Command Query Options and Query Returns
Table 26 :SBUS<n>:SPI Commands Summary
Command Query Options and Query Returns
:SBUS<n>:SPI:BITorder
<order> (see
page 520)
:SBUS<n>:SPI:BITorder
? (see page 520)
<order> ::= {LSBFirst | MSBFirst}
:SBUS<n>:SPI:CLOCk:SL
OPe <slope> (see
page 521)
:SBUS<n>:SPI:CLOCk:SL
OPe? (see page 521)
<slope> ::= {NEGative | POSitive}
