Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 95
:SBUS<n>:IIC:TRIGger:
PATTern:ADDRess
<value> (see
page 498)
:SBUS<n>:IIC:TRIGger:
PATTern:ADDRess? (see
page 498)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
PATTern:DATA <value>
(see page 499)
:SBUS<n>:IIC:TRIGger:
PATTern:DATA? (see
page 499)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
PATTern:DATa2 <value>
(see page 500)
:SBUS<n>:IIC:TRIGger:
PATTern:DATa2? (see
page 500)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
QUALifier <value>
(see page 501)
:SBUS<n>:IIC:TRIGger:
QUALifier? (see
page 501)
<value> ::= {EQUal | NOTequal |
LESSthan | GREaterthan}
:SBUS<n>:IIC:TRIGger[
:TYPE] <type> (see
page 502)
:SBUS<n>:IIC:TRIGger[
:TYPE]? (see
page 502)
<type> ::= {STARt | STOP | READ7
| READEprom | WRITe7 | WRITe10 |
NACKnowledge | ANACk | R7Data2 |
W7Data2 | RESTart}
Table 24 :SBUS<n>:IIC Commands Summary (continued)
Command Query Options and Query Returns
Table 25 :SBUS<n>:LIN Commands Summary
Command Query Options and Query Returns
:SBUS<n>:LIN:PARity
{{0 | OFF} | {1 |
ON}} (see page 506)
:SBUS<n>:LIN:PARity?
(see page 506)
{0 | 1}
:SBUS<n>:LIN:SAMPlepo
int <value> (see
page 507)
:SBUS<n>:LIN:SAMPlepo
int? (see page 507)
<value> ::= {60 | 62.5 | 68 | 70
| 75 | 80 | 87.5} in NR3 format
:SBUS<n>:LIN:SIGNal:B
AUDrate <baudrate>
(see page 508)
:SBUS<n>:LIN:SIGNal:B
AUDrate? (see
page 508)
<baudrate> ::= integer from 2400
to 625000 in 100 b/s increments
:SBUS<n>:LIN:SOURce
<source> (see
page 509)
:SBUS<n>:LIN:SOURce?
(see page 509)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:LIN:STANdard
<std> (see page 510)
:SBUS<n>:LIN:STANdard
? (see page 510)
<std> ::= {LIN13 | LIN20}
