Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 93
:SBUS<n>:I2S:SOURce:C
LOCk <source> (see
page 481)
:SBUS<n>:I2S:SOURce:C
LOCk? (see page 481)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:I2S:SOURce:D
ATA <source> (see
page 482)
:SBUS<n>:I2S:SOURce:D
ATA? (see page 482)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:I2S:SOURce:W
SELect <source> (see
page 483)
:SBUS<n>:I2S:SOURce:W
SELect? (see
page 483)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:I2S:TRIGger
<operator> (see
page 484)
:SBUS<n>:I2S:TRIGger?
(see page 484)
<operator> ::= {EQUal | NOTequal
| LESSthan | GREaterthan |
INRange | OUTRange | INCReasing |
DECReasing}
:SBUS<n>:I2S:TRIGger:
AUDio <audio_ch> (see
page 486)
:SBUS<n>:I2S:TRIGger:
AUDio? (see page 486)
<audio_ch> ::= {RIGHt | LEFT |
EITHer}
:SBUS<n>:I2S:TRIGger:
PATTern:DATA <string>
(see page 487)
:SBUS<n>:I2S:TRIGger:
PATTern:DATA? (see
page 488)
<string> ::= "n" where n ::=
32-bit integer in signed decimal
when <base> = DECimal
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $} when <base> =
BINary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
:SBUS<n>:I2S:TRIGger:
PATTern:FORMat <base>
(see page 489)
:SBUS<n>:I2S:TRIGger:
PATTern:FORMat? (see
page 489)
<base> ::= {BINary | HEX |
DECimal}
Table 23 :SBUS<n>:I2S Commands Summary (continued)
Command Query Options and Query Returns
