Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 91
Table 21 General :SBUS<n> Commands Summary
Command Query Options and Query Returns
:SBUS<n>:DISPlay {{0
| OFF} | {1 | ON}}
(see page 456)
:SBUS<n>:DISPlay?
(see page 456)
{0 | 1}
:SBUS<n>:MODE <mode>
(see page 457)
:SBUS<n>:MODE? (see
page 457)
<mode> ::= {CAN | I2S | IIC | LIN
| SPI | UART}
Table 22 :SBUS<n>:CAN Commands Summary
Command Query Options and Query Returns
n/a :SBUS<n>:CAN:COUNt:ER
Ror? (see page 460)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:CAN:COUNt:OV
ERload? (see
page 461)
<frame_count> ::= integer in NR1
format
:SBUS<n>:CAN:COUNt:RE
Set (see page 462)
n/a n/a
n/a :SBUS<n>:CAN:COUNt:TO
Tal? (see page 463)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:CAN:COUNt:UT
ILization? (see
page 464)
<percent> ::= floating-point in
NR3 format
:SBUS<n>:CAN:SAMPlepo
int <value> (see
page 465)
:SBUS<n>:CAN:SAMPlepo
int? (see page 465)
<value> ::= {60 | 62.5 | 68 | 70
| 75 | 80 | 87.5} in NR3 format
:SBUS<n>:CAN:SIGNal:B
AUDrate <baudrate>
(see page 466)
:SBUS<n>:CAN:SIGNal:B
AUDrate? (see
page 466)
<baudrate> ::= integer from 10000
to 1000000 in 100 b/s increments
:SBUS<n>:CAN:SIGNal:D
EFinition <value>
(see page 467)
:SBUS<n>:CAN:SIGNal:D
EFinition? (see
page 467)
<value> ::= {CANH | CANL | RX |
TX | DIFFerential | DIFL | DIFH}
:SBUS<n>:CAN:SOURce
<source> (see
page 468)
:SBUS<n>:CAN:SOURce?
(see page 468)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> |} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
