Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 85
n/a :MEASure:VTIMe?
<vtime>[,<source>]
(see page 379)
<vtime> ::= displayed time from
trigger in seconds in NR3 format
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>} for
DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion | MATH |
WMEMory<r>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= voltage at the
specified time in NR3 format
:MEASure:VTOP
[<source>] (see
page 380)
:MEASure:VTOP?
[<source>] (see
page 380)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= voltage at the
top of the waveform in NR3 format
:MEASure:WINDow
<type> (see page 381)
:MEASure:WINDow? (see
page 381)
<type> ::= {MAIN | ZOOM | AUTO}
:MEASure:XMAX
[<source>] (see
page 382)
:MEASure:XMAX?
[<source>] (see
page 382)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
:MEASure:XMIN
[<source>] (see
page 383)
:MEASure:XMIN?
[<source>] (see
page 383)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
Table 16 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
