Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
34
Status Reporting
Status Reporting Data Structures 831
Status Byte Register (STB) 833
Service Request Enable Register (SRE) 835
Trigger Event Register (TER) 836
Output Queue 837
Message Queue 838
(Standard) Event Status Register (ESR) 839
(Standard) Event Status Enable Register (ESE) 840
Error Queue 841
Operation Status Event Register (:OPERegister[:EVENt]) 842
Operation Status Condition Register (:OPERegister:CONDition) 843
Arm Event Register (AER) 844
Overload Event Register (:OVLRegister) 845
Mask Test Event Event Register (:MTERegister[:EVENt]) 846
Clearing Registers and Queues 847
Status Reporting Decision Chart 848
IEEE 488.2 defines data structures, commands, and common bit
definitions for status reporting (for example, the Status Byte Register and
the Standard Event Status Register). There are also instrument- defined
structures and bits (for example, the Operation Status Event Register and
the Overload Event Register).
An overview of the oscilloscope's status reporting structure is shown in
the following block diagram. The status reporting structure allows
monitoring specified events in the oscilloscope. The ability to monitor and
report these events allows determination of such things as the status of an
operation, the availability and reliability of the measured data, and more.
