82 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:MEASure:SOURce
<source1>
[,<source2>] (see
page 362)
:MEASure:SOURce? (see
page 362)
<source1,2> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r> |
EXTernal} for DSO models
<source1,2> ::= {CHANnel<n> |
DIGital<d> | FUNCtion | MATH |
WMEMory<r> | EXTernal} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= {<source> |
NONE}
:MEASure:STATistics
<type> (see page 364)
:MEASure:STATistics?
(see page 364)
<type> ::= {{ON | 1} | CURRent |
MEAN | MINimum | MAXimum | STDDev
| COUNt}
ON ::= all statistics returned
:MEASure:STATistics:I
NCRement (see
page 365)
n/a n/a
:MEASure:STATistics:R
ESet (see page 366)
n/a n/a
n/a :MEASure:TEDGe?
<slope><occurrence>[,
<source>] (see
page 367)
<slope> ::= direction of the
waveform
<occurrence> ::= the transition
to be reported
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>} for
DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion | MATH |
WMEMory<r>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= time in
seconds of the specified
transition
Table 16 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
