816 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
32 Obsolete and Discontinued Commands
:SBUS<n>:LIN:SIGNal:DEFinition
(see page 860)
Command Syntax
:SBUS<n>:LIN:SIGNal:DEFinition <value>
<value> ::= {LIN | RX | TX}
The :SBUS<n>:LIN:SIGNal:DEFinition command sets the LIN signal type.
These signals can be set to:
Dominant low signals:
• LIN — the actual LIN single- end bus signal line.
• RX — the Receive signal from the LIN bus transceiver.
• TX — the Transmit signal to the LIN bus transceiver.
Query Syntax
:SBUS<n>:LIN:SIGNal:DEFinition?
The :SBUS<n>:LIN:SIGNal:DEFinition? query returns the current LIN signal
type.
Return Format
<value><NL>
<value> ::= LIN
See Also • "Introduction to :TRIGger Commands" on page 641
• ":TRIGger:MODE" on page 648
• ":SBUS<n>:LIN:SIGNal:BAUDrate" on page 508
• ":SBUS<n>:LIN:SOURce" on page 509
NOTE
This command is available, but the only legal value is LIN.
