804 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
32 Obsolete and Discontinued Commands
:MEASure:VSTOp
(see page 860)
Command Syntax
:MEASure:VSTOp <vstop_argument>
<vstop_argument> ::= value for Y2 cursor
The :MEASure:VSTOp command moves the vertical marker 2 (Y2 cursor) to
the specified value corresponding to the selected source. The source can
be selected by the MARKer:X2Y2source command.
Query Syntax
:MEASure:VSTOp?
The :MEASure:VSTOp? query returns the current value of the Y2 cursor.
Return Format
<value><NL>
<value> ::= value of the Y2 cursor in NR3 format
See Also • "Introduction to :MARKer Commands" on page 310
• "Introduction to :MEASure Commands" on page 330
• ":MARKer:Y1Position" on page 317
• ":MARKer:Y2Position" on page 318
• ":MARKer:YDELta" on page 319
• ":MARKer:X2Y2source" on page 315
• ":MEASure:SOURce" on page 362
• ":MEASure:TDELta" on page 793
• ":MEASure:TSTArt" on page 797
NOTE
The short form of this command, VSTO, does not follow the defined Long Form to Short
Form Truncation Rules (see page 862). The normal short form, VST, would be the same for
both VSTArt and VSTOp, so sending VST for the VSTOp command produces an error.
NOTE
The :MEASure:VSTOp command is an obsolete command provided for compatibility to
previous oscilloscopes. Use the :MARKer:Y2Position command (see page 318) instead.
