790 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
32 Obsolete and Discontinued Commands
:HARDcopy:PDRiver
(see page 860)
Command Syntax
:HARDcopy:PDRiver <driver>
<driver> ::= {AP2Xxx | AP21xx | {AP2560 | AP25} | {DJ350 | DJ35} |
DJ6xx | {DJ630 | DJ63} | DJ6Special | DJ6Photo |
DJ8Special | DJ8xx | DJ9Vip | OJPRokx50 | DJ9xx | GVIP |
DJ55xx | {PS470 | PS47} {PS100 | PS10} | CLASer |
MLASer | LJFastraster | POSTscript}
The HARDcopy:PDRiver command sets the hardcopy printer driver used
for the selected printer.
If the correct driver for the selected printer can be identified, it will be
selected and cannot be changed.
Query Syntax
:HARDcopy:PDRiver?
The :HARDcopy:PDRiver? query returns the selected hardcopy printer
driver.
Return Format
<driver><NL>
<driver> ::= {AP2X | AP21 | AP25 | DJ35 | DJ6 | DJ63 | DJ6S | DJ6P |
DJ8S | DJ8 | DJ9V | OJPR | DJ9 | GVIP | DJ55 | PS10 |
PS47 | CLAS | MLAS | LJF | POST}
See Also • "Introduction to :HARDcopy Commands" on page 288
NOTE
The :HARDcopy:PDRiver command is an obsolete command provided for compatibility to
previous oscilloscopes. Use the :HARDcopy:APRinter (see page 290) command instead.
