770 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
32 Obsolete and Discontinued Commands
:CHANnel<n>:INPut (see
page 778)
:CHANnel<n>:IMPedance
(see page 227)
:CHANnel<n>:PMODe (see
page 779)
none
:DISPlay:CONNect (see
page 780)
:DISPlay:VECTors (see
page 262)
:DISPlay:ORDer (see page 781)none
:ERASe (see page 782):DISplay:CLEar (see page 257)
:EXTernal:PMODe (see
page 783)
none
FUNCtion1, FUNCtion2 :FUNCtion Commands (see
page 269)
ADD not included
:FUNCtion:SOURce (see
page 784)
:FUNCtion:SOURce1 (see
page 282)
Obsolete command has ADD,
SUBTract, and MULTiply
parameters; current command
has GOFT parameter.
:FUNCtion:VIEW (see
page 785)
:FUNCtion:DISPlay (see
page 273)
:HARDcopy:DESTination (see
page 786)
:HARDcopy:FILename (see
page 787)
:HARDcopy:FILename (see
page 787)
:RECall:FILename (see
page 427)
:SAVE:FILename (see
page 427)
:HARDcopy:GRAYscale (see
page 788)
:HARDcopy:PALette (see
page 301)
:HARDcopy:IGColors (see
page 789)
:HARDcopy:INKSaver (see
page 293)
:HARDcopy:PDRiver (see
page 790)
:HARDcopy:APRinter (see
page 290)
:MEASure:LOWer (see
page 791)
:MEASure:DEFine:THResholds
(see page 337)
MEASure:DEFine:THResholds
can define absolute values or
percentage
:MEASure:SCRatch (see
page 792)
:MEASure:CLEar (see
page 335)
:MEASure:TDELta (see
page 793
)
:MARKer:XDELta (see
page 316)
:MEASure:THResholds (see
page 794)
:MEASure:DEFine:THResholds
(see page 337)
MEASure:DEFine:THResholds
can define absolute values or
percentage
Obsolete Command Current Command Equivalent Behavior Differences
