Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
32
Obsolete and Discontinued Commands
Obsolete commands are older forms of commands that are provided to
reduce customer rework for existing systems and programs (see"Obsolete
Commands" on page 860).
Obsolete Command Current Command Equivalent Behavior Differences
ANALog<n>:BWLimit :CHANnel<n>:BWLimit (see
page 224)
ANALog<n>:COUPling :CHANnel<n>:COUPling (see
page 225)
ANALog<n>:INVert :CHANnel<n>:INVert (see
page 228)
ANALog<n>:LABel :CHANnel<n>:LABel (see
page 229)
ANALog<n>:OFFSet :CHANnel<n>:OFFSet (see
page 230)
ANALog<n>:PROBe :CHANnel<n>:PROBe (see
page 231)
ANALog<n>:PMODe none
ANALog<n>:RANGe :CHANnel<n>:RANGe (see
page 237)
:CHANnel:ACTivity (see
page 774)
:ACTivity (see page 155)
:CHANnel:LABel (see
page 775)
:CHANnel<n>:LABel (see
page 229) or
:DIGital<n>:LABel (see
page 250)
use CHANnel<n>:LABel for
analog channels and use
DIGital<n>:LABel for digital
channels
:CHANnel:THReshold (see
page 776)
:POD<n>:THReshold (see
page 423) or
:DIGital<d>:THReshold (see
page 253)
:CHANnel2:SKEW (see
page 777)
:CHANnel<n>:PROBe:SKEW
(see page 234)
